Prospect

systems

Operation systems

LINUX

Systems resource

Multichannel record,playback,web,
USB backup simultaneously

Interface

GUI

16 bits full colour GUI,Support Mouse

Display

1/4

ch

1/4/8

ch

1/4/8/
9/ 16
ch

1/4/8/9/
16/24
ch

1/4/8/9/16
/24 /32
ch

Language

English, Simplified Chinese, Traditional
Chinese, Italian, Spanish, Japanese, Russian, French, German, Portuguese, Polish, Arabic, Greek

Video

Video standard

PAL（625 lines, 50 f / s）；
NTSC（525 line, 60 f / s）

Display

PAL:D1 (704 × 576) ；
NTSC:D1（704 × 480）

Playback

PAL: CIF(352 × 288), D1
（ 704 × 576)；

NTSC: CIF(352 × 240), D1
（ 704 × 480）

Frame rate

PAL:800fps; NTSC:960 fps

Motion    detection

396 (22 × 18）detection area, multi sensitivity

Audio

Audio

G711A

Record& Playback

Record model

Manual >alarm >motion detection >timer

playback

1ch、multi-ch

Search

Time, loglist, event、 Channel

Backup

HDD/Space

Audio： 28.8M  / h＋Video：
25 ～ 450M / h

Storage

HDD、 WEB

Backup model

WEB、USB、USB DVD -RW

Port

Video input

16 ch BNC

Video output

1 ch BNC , 1 ch VGA output

Audio input

16ch RCA

Audio output

1ch RCA

Alarm input

8ch

Alarm output

1ch

HDMI

Support

WEB

RJ45 10M/100/1000M  Ethernet

PTZ

1  RS485

USB

2 USB

HDD

2 SATA ,2000G*2

Others

Power

AC:100-250V  50/60Hz

Consumption

About 4０W

Operating temperature

-10 ℃ - ＋ 55 ℃

Humidity

10% － 90%

Size

430*85*320mm

Weight

6.5kg
